InfiRay - Finder Series - FH25R - Thermal Range Finding Monocular

The Finder series products are light and easy to carry, especially suitable for one-handed operation that can be put in your pocket anytime and anywhere. The compact design makes the Finder the best choice for outdoor investigation and hunting as it includes an inbuilt thermal range finder.



Key Features:

  • High Image Quality

The advanced image processing ability of the InfiRay detector, which has high performance electronics and optimized infrared optics, creates excellent image clarity and provides better detection and classification, both in day and night.

  • 12µm Thermal Imaging Sensor and Long Detection Range 1298 m

High performance 12μm pixel pitch detectors are embedded. Powerful objective lens in combination with a 12µm professional grade thermal imaging sensor provides exceptional detection capabilities. A standard 1,7 m (5.58 ft) tall object can be detected at a 1300 m (1420 yds) distance in complete darkness.

 InfiRay - Finder FH25R - Thermal Range Finding Monocular



  • High Image Frequency 50 Hz

The 50 Hz refresh rate guarantees that you will capture every moment that you are interested in.

  • HD Micro Display

1280×960 high-resolution internal display offers sharp image and vivid colours.

  • Integrated Laser Rangefinder (LRF) 600m

The Finder series has a built-in laser ranging module, which helps to quickly and accurately capture and display the target distance. The ranging accuracy is ± 1 m and the maximum ranging distance is 600 m. Accurate distance readings help to quickly assess the size of the territory and distance to targets. Integrated, precision laser rangefinder provides accurate rangefinding, it provides both single ranging and continuous ranging modes. Continuous ranging can be quickly activated to adapt to the constantly changing distance of the observed object.

 InfiRay - Finder FH25R - Thermal Range Finding Monocular



  • Pocket Machine

The compact size and light weight makes it easy to carry and operate with one hand. It can be put into the pocket anytime and anywhere. The Finder weighs only 320g which is lighter than conventional rangefinders, but much more powerful.

Compact size of thermal imager makes it an optimal portable unit for scouting and spotting.

 InfiRay - Finder FH25R - Thermal Range Finding Monocular

  • Infrared Sensor Switch

By sensing the reflection, the infrared sensor switch controls the display on and off automatically which saves power and extends the device's operation time. It also has the advantage of high sensitivity, strong anti-interference ability and stable working performance.

  • Built-in Video Recorder and WiFi Connection

With built-in storage space, the Finder series supports to save the interesting moments in the form of photos or video for sharing with colleagues, friends and family. It can store many hours of recorded video and tens of thousands of photos.

 InfiRay - Finder FH25R - Thermal Range Finding Monocular

  • App Supported

Built in Wi-Fi module provides connectivity of Finder with Android or iOS smartphones or tablets. The smartphone and thermal imager combination offer a set of unique features such as direct image streaming, downloading and sharing recorded files, firmware.

  • Built-in Accelerometer and Digital Compass

Built-in accelerometer and digital compass improves accuracy by precisely identifying cant and angles.

 InfiRay - Finder FH25R - Thermal Range Finding Monocular

Finder Series Specifications

  Main

FL25R

FH25R

Sensor
384×288 - 12μm - NETD, mK≤40
640×512 - 12μm - NETD, mK≤40
Objective lens, mm
25 25
Magnification, x
2.5-10 1.5-6.0
Detection range, m
1298 1298
  Sensor

Type
uncooled
uncooled
Resolution, pixels
384×288
640×512
Frame rate, Hz
50
50
  Optics


Objective lens, mm 25 25
Field of View, degrees
10.5°×7.9° 17.5°×14°
Magnification, x
2.5-10 1.5-6.0
Digital Zopm, x x1/x1.5/x2/x2.5 /x3 /x3.5 x4 x1/x1.5/x2/x2.5 /x3 /x3.5 x4
  Display


Resolution, pixels
1280x960 LCOS 1280x960 LCOS
Thermal Palettes
Black, White, Red Hot, Rainbow
Black, White, Red Hot, Rainbow
  Range Performance


Detection range (person), m
1298 1298
  Video Recorder


Amount of built-in memory, GB
16 16
  Laser Rangefinder

Laser Rangefinder Range, m
Max 600 ±1
Max 600 ±1
  Power Supply


Battery type
Internal Battery - Li-ion Internal Battery - Li-ion
Operating time on battery pack (at t=22°C), h *
6
6
  Wi-Fi


Max Line-of-sight reception range m
15
15
  Weight & Size


Dimensions, mm
70x52x130 70x52x130
Weight, kg
0.32
0.32
  Warranty
3 years
3 years
  Trade Data


SKU (Model #)
FL25R
FH25R
