GRIZZLY - MUZZLE BRAKE BLUED - THREAD: 1/2X24TPI - DIA: 14MM - SKU:GBS14
Australian made muzzle brakes.
The GBS14 Grizzly muzzle brake is designed for calibres up to .30cal. These brakes are an easy, convenient screw on design that do not require any crush washers or special tools. Just screw the muzzle brake on all the way to the shoulder of your barrel and then fasten tight with the tool provided. Due to the perfectly aligned machined gas ports, this design disperses energy evenly around the brake, creating greater balance thus eliminating deviation from the muzzle blast.
PLEASE NOTE - Calibres over .30cal must be modified by a gunsmith.
The GBS14 standard thread size is:
- 1/2x24TPI
The GBS14 Dimensions are 14mm (0.944in) diameter at the tapered end, 17.4mm (2.489in) at the base, 56.70mm (2.234in) in length and it weighs 40 grams (1.41oz).
The GBS14 Barrel profile match perfectly for the following firearm for a flush fitting muzzle brake:
- Ruger M77
- Steyr Pro Hunter
The GBS14 is also suitable for many other firearms for a flush fitting muzzle brake that have this barrel profile. It can also be fitted to a smaller barrel profile, if the 1/2x24TPI thread size is what you require and a slightly larger diameter brake is prefered.
